Description
xFeatures:
- Integrated AC & DC disconnect switches
- Touch safe DC Fuse holders adds convenience and safety
- Support Anti-PID function, improve system efficiency
- Maximum efficiency up to 99.00%
- High precision intelligent strings monitoring, reduce fault location time
- Ethernet/ RS485 multiple communication modes,flexible monitoring
- Built-in AC and DC lightning protection module, all-around lightning protection
- WiFi monitoring available-Android and Apple App store available
Documents:
Solis 125kW Three Phase on-grid solar Inverter Datasheet.pdf
| Current DC | |
| Max. Input Current | 150A |
| Display Specification | |
| Display | LCD, 2×20 Z. |
| INPUT | |
| Rated grid frequency / rated grid voltage | 50/60Hz |
| Output | |
| Topology | Transformerless |
| TECHNICAL SPECIFICATION | |
| MPPT Voltage Range | 860-1450V |
| Rated Voltage | 950V |
| Start-up Voltage | 900V |
| General Specification | |
| Communication | RS485; Ethernet/PLC/WiFi/GPRS (optional) |
| Max. Efficiency | 99.1% |
| Max. input power per MPPT | 187.5kW |
| Max. input voltage | 1500V |
| Max. Short Circuit current | 300A |
| Rated Grid Voltage | 3/PE, 600V |
| Rated Output Power | 125kW |
| Weight | 84kg |
| Dimensions | 1178mm*713.5mm*315mm |
