xOverview:
The Xerox G4 Pro 15.2K Inverter is our line of benchmark three phase solar inverters designed for use in small decentralized residential, commercial, and industrial systems. These high-performance and high-delivery inverters are extremely easy to install and commission and are designed to be reliable and low-maintenance.
Reliability:
The Xerox G4 Pro 15.2K Inverter was designed in accordance with international quality and safety standards and is a robust family of extremely reliable solar inverters. The IP66 certification rating also means these inverters will maintain their reliability in a wide range of environmental conditions. From a purely technical angle, the DC reverse polarity protection, AC sensitive residual current monitoring, and built-in surge protection functions ensure reliable and safe long-term operation.
Powerful:
Our Xerox G4 Pro 15.2K Inverter solar inverters are designed for power. A maximum DC input of 32A and a wide MPP voltage range ensure highly optimized energy performance for bi-facial and large-area PV modules. These dynamic solar inverters also allow up to 150% oversizing of the attached PV array, making them perfect for residential rooftop solar installations that vary greatly in their design, scale, and purpose.
Easy to Install:
The Xerox G4 Pro 15.2K Inverter is designed to be installed quickly and easily with standard tools and the Phoenix Contact DC connectors make these inverters compatible with a wide range of solar panels. Optional Plug & Play and 4G dongles connect them to the internet and allow up to five to be monitored by Solplanet’s user-friendly mobile application. Users can view real-time solar installation data, configure their inverters, and receive system alerts, right in the palm of their hand.
The Xerox G4 Pro 15.2K Pro Inverter feature a sleek design that is compact, wall-mountable, and IP66-rated, making them weatherproof and extremely durable. They have a wide MPP voltage range with a possible 150% oversizing of the PV array for flexibility and efficiency under a variety of conditions. Do you need an inverter that can power an energy-hungry system? The Xerox G4 Pro 15.2K inverter feature a maximum input current of 16A per string making them a perfect pairing for bi-facial and large-area PV arrays.
| Summary | |
| Voltage range | 150V to 1000V |
| HARDWARE FEATURES | |
| Degree of protection | IP66 |
| TECHNICAL SPECIFICATION | |
| Array Power | 22500Wp |
| Nominal voltage | 230, 3/N/PE |
| Rated Power | 15000W |
| General Specification | |
| Current | 48A / 30A |
| Input Voltage | 630V |
