Description
xFeatures
- Built-In WiFi: Enables real-time monitoring and control through a dedicated mobile app, offering convenience and insights into system performance.
- Durable IP21 Rated Protection: Engineered to withstand environmental factors, ensuring long-lasting durability.
- Dual Output Design: Separates smart loads from heavy loads for optimized power distribution and efficiency.
- Grid-Tied Solar Integration: Allows seamless connection to the grid, enhancing energy utilization and enabling net metering options.
- Battery-Less Operation: Operates without the need for batteries, reducing costs and complexity while still supporting energy independence.
- Battery Management System (BMS): Extends battery life and optimizes performance when used with batteries, ensuring intelligent charging and discharging cycles.
| HARDWARE FEATURES | |
| Efficiency | 95% |
| Output Voltage Range | 184 - 264.5 VAC or 195.5 - 253 VAC (Selectable) |
| TECHNICAL SPECIFICATION | |
| Start-up Voltage | 120VDC |
| General Specification | |
| Feeding Capacity | 150 VDC |
| Maximum PV Input Power | 7500W |
| MPP voltage range | 120 VDC ~ 430 VDC |
| Nominal Output Powe | 18 A |
| Nominal Output Voltage | 220/230/240 VAC |
| Number of MPPT | 2 / 27A (MAX 40A) |
| Phase | Single Phase |
| Power factor | > 0.99 |
| Rated Output Power | 5500W |
| Solar Panel Specification | |
| Nominal DC Voltage [V] | 360 VDC / 500 VDC |
