xOVERVIEW:
The Knox 110KW On Grid Solar Inverter is a three-phase, non-isolated inverter designed for large-scale commercial and utility solar applications, featuring an IP66 rating for outdoor durability and advanced features like 10 MPPTs for flexible PV array design.
Features:
- Higher Yields: The inverter allows for 150% PV array oversizing, which results in higher energy yields. It also incorporates a "ShadeSol" shadow management function to maximize performance in partially shaded conditions.
- Flexible Design: With 10 MPPTs (Maximum Power Point Trackers), it offers flexible PV array design options.
- Durability: The IP66-rated design makes it suitable for outdoor use, and it is built to withstand local temperature and voltage fluctuations, a feature appreciated in local reviews in Pakistan.
- User-Friendly: It features 24/7 system monitoring and quick setup via Solplanet apps.
- Safety: It includes Type II surge protection for both DC and AC, as well as DC reverse-polarity protection. It has a fuse-free design with string-level management.
| Frequency | |
| MPP Voltage range/ rated input voltage | 200V - 1000 V / 630 V |
| HARDWARE FEATURES | |
| Degree of protection | IP66 |
| Output | |
| Topology | Non-isolated |
| TECHNICAL SPECIFICATION | |
| AC Connection | OT/DT Terminal (Max.240mm2) |
| AC Nominal Voltage | 220 V / 380 V 230 V / 400 V |
| DC Connection | Phoenix Contact |
| General Specification | |
| AC voltage range | 312 V - 528 V |
| Max Input Voltage | 1100 V |
| Maximum PV Array Power | 165000 Wp STC |
| Operating Temperature Range | -25°C … +60°C |
| Phase | Three Phase |
| Protection Class | I / AC: III; DC: II |
| Rated Active Power | 110000 W |
| Type | Three Phase On Grid Solar Inverter |
| Weight | 85 kg |
| Dimensions | 984/ 640 / 330 mm |
