xProduct Details:
The Inverex Veyron II Premium 4200W-24V MPPT Solar Inverter combines high power output with smart technology for flexible and efficient solar energy management.
Features:
- IP54-GRADE DESIGN
- BUILT-IN WIFI WITH APP FOR MOBILE MONITORING AND OTA FIRMWARE UPGRADE
- RESERVED COMMUNICATION PORT FOR BMS
- DUAL OUTPUTS FOR SMART LOAD MANAGEMENT
- BUILT-IN 4.3" TOUCHED COLORED LCD
- MAXIMUM PV INPUT CURRENT 27A
- MAXIMUM CHARGING CURRENT 150A
- BUILT-IN EXTERNAL CT SENSOR FOR 100% SELF-CONSUMPTION
- BATTERY INDEPENDENT DESIGN
- BATTERY EQUALIZATION EXTENDS LIFECYCLE
| POWER | |
| Charge Voltage | 27 VDC |
| Summary | |
| communication interface | RS232/RS485/CAN/Wifi |
| Voltage range | 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances) |
| HARDWARE FEATURES | |
| Battery Voltage | 24 VDC |
| Efficiency | 93% |
| Operating Voltage | 60~450 VDC |
| Output | |
| Transfer Time | 10 ms (For Personal Computers) 20 ms (For Home Appliances) |
| TECHNICAL SPECIFICATION | |
| Array Power | 8000W |
| Rated Power | 4200VA/4200W |
| Surge Power | 8400VA |
| General Specification | |
| AC Voltage | 230VAC ± 5% |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) |
| Humidity | 5% to 95% Relative Humidity(Non-condensing) |
| Voltage | 230 VAC |
| Waveform | Pure sine wave |
| Weight | 10.2 kg |
| Dimension | 117.4x333.8x460.4 mm |
