The GoodWe Smart DT series inverter is specially designed for three-phase home solar systems, covering a wide power range of 05kW, 10kW, 15kW, 25kW & 50kW. The integrated two MPPTs allow two-array inputs from different roof orientations. The SDT series inverter is small, light and easy to install. Suitable for both outdoor and indoor installations, this inverter offers a quiet operation thanks to its fan less, natural convection cooling.
| Frequency | |
| Nominal Output Frequency (Hz) | 50/60 |
| TECHNICAL SPECIFICATION | |
| Anti-island Protection Monitoring | Integrated |
| Input Reverse Polarity Protection | Integrated |
| Insulation Resistor Detection | Integrated |
| Max Input Current (A) | 30/30/20/20 |
| Max. Output Apparent Power (VA) | 55000, 57000@415VAc |
| Max. Output Current (A) | 80 |
| Max. Output Power | 55000, 57000@415VAc |
| Max.Short Current (A) | 38/38/25/25 |
| MPPT Range of load (V) | 520~850 |
| No. of input Strings per Tracker | 3/3/2/2 |
| Output THDi (@Nominal Output) | <3% |
| Start Voltage [V] | 200 |
| General Specification | |
| Max. Efficiency | 98.7% |
| No. of MPP Trackers | 4 |
| Output over Current Protection | Integrated |
| Output Power Factor | ~1(Adjustable from 0.8 leading to 0.8 lagging) |
| Solar Panel Specification | |
| Euro Efficiency (at 600Vdc) | 98.3% |
| Max. DC power [W] | 65000 |
| Max. DC Voltage [V] | 1000 |
| MPPT Voltage Range [V] | 200-850 |
| Nominal DC Voltage [V] | 620 |
| Nominal Output Power (W) | 50000 |
| Nominal Output Voltage (V) | 400, 3L/N/PE |
| Open Short Protection | Integrated |
| Residual Current Monitoring Unit | Integrated |
