Goodwe 100Kw On-Grid Solar Inverter

The new HT 1100Vdc Series (73-136 KW) is the ultimate high-power string inverter for the C&I sector. The HT series offers up to 12 MPPTs, and is compatible with Bi-facial modules, with a higher threshold of DC current (Max. 15A per string). It includes PLC communication, internal humidity detection. Configuration can be easily done via Bluetooth and firmware diagnosis & upgrading can be operated remotely. The HT series seamlessly incorporates different sets of technical strengths designed to achieve higher savings in the installation, enhance productivity and diversify available monitoring options, taking safety to the maximum possible level in accordance with the strictest industry standards.

Display Specification
Display	LED(Standard), LCD(Optional), Bluetooth+APP
Summary
Active Power	Max AC: 110kW
Apparent Power	Max AC: 110kVA
Power Factor	Output: ~1 (Adjustable from 0.8 leading to 0.8 lagging)
Relative Humidity	0~100%
Output Current	Max: 167A
HARDWARE FEATURES
Efficiency	Max: 98.6% | European: 98.3%
Input Current	Max per MPPT: 10*30A
Output
Nominal Output Voltage	400, 3L/N/PE or 3L/PE V
TECHNICAL SPECIFICATION
DC Input Power	Max: 150kW
Nominal Grid Frequency	AC: 50/60Hz
Operating Altitude	Max: ≤4000(m)
Protection degree	IP66
Start-up Voltage	200V
General Specification
Communication	RS485 or PLC or WiFi
Harmonic Distortion	Max Total: <3%
MPPT Operating range	Voltage: 180~1000V
No. of MPP Trackers	10
Nominal Output Power	100kW
Operating Temperature	Range: -30~60 (°C)
Short Circuit Current	Max per MPPT: 10*45A
Weight	93.5
Input Voltage	Max: 1100V
Dimensions	(W × H × D mm): 1008 × 678 × 343
Input
Nominal Input Voltage	600V
