Description
xFeatures:
Smart:
- Full automatic operation, no need programming, user-friendly
- Modular design, easy install , operate & maintain
- GPRS or SPMCS remote control for option
Efficient:
- 1:1 match to AC pumps with strong overload capacity
- 30% more water output with advanced inverter control algorithm
- Maximum power point tracking (MPPT) efficiency reach 99% with advanced MPPT algorithm
- Good ROI (Return on Investment) against diesel powered pumping
Reliable:
- Hybrid function – support solar power, grid power/generator input.
- Multi power sources work as complementary to achieve system working 24 hours per day
- IP65 design, continuous full-load operation between -10℃ to +60℃
- Compatible with all AC pump types
Comprehensive Protections:
- Soft start
- DC Input Anti-reverse
- AC Input/Output Phase lost(3Phase)
- AC Output Short Circuit
- AC Output Unbalance (3Phase)
- Pump Dry run protection By sensor/ software
- Water Over Flow of Tank
- Solar Low power
- Over Load
- AC Output Over Current
| Display Specification | |
| Display | LCD Display |
| INPUT | |
| Vmp Voltage | 400V |
| Summary | |
| Output Frequency | 50-60Hz (support Program range 15 to 60Hz) |
| Output Current | 17A |
| HARDWARE FEATURES | |
| Efficiency | 99% |
| Input Current | 26A |
| TECHNICAL SPECIFICATION | |
| Cooling Method | Force Cooling by Fan (IP68) |
| Rated Input Current | 17.3A |
| General Specification | |
| 4G/wifi monitor & controller | Optional |
| Drive Mode | Variable Frequency drive 3 phase |
| Humidity | 95%RH |
| Hybrid Mode | AC Supplement automatic when solar low power and ac disconnect while solar power recovery |
| Max Adapted AC Pump Horse | 10HP |
| Max Adapted AC Pump Power | 7500W |
| Max Voc Voltage | 800V |
| MPPT | 99% |
| Noise | <50dB |
| Note | Automatic MMPT function to identify the Voc and Vmp od solar panel, No need programming |
| Operating Temperature Range | -10 t0 60, Above 60°C Need to derate load |
| Recommend Vmp Voltage | 500vmp<DC input<750VOC (Only Solar Input) 540Vmp<DC input <700Voc (Only hybrid Input) |
| Using altitude | <3000m,Above 3000m need to derate load |
| Voltage | 3 Phase 380/400/440V |
| Water Level Sensor Well Tank | Yes |
| WaterProof | IP65 |
| Weight | 9.5kg |
| Dimensions | 500*350*220mm |
| Output Voltage | 380/400/440 |
