xOverview:
Smart:
Full automatic operation, no need programming, user-friendly Modular design, easy install , operate & maintain GPRS or SPMCS remote control for option.
Efficient:
1:1 match to AC pumps with strong overload capacity 30% more water output with advanced inverter control algorithm Maximum power point tracking (MPPT) efficiency reach 99% with advanced MPPT algorithm Good ROI (Return on Investment) against diesel powered pumping
Reliable:
Hybrid function – support solar power, grid power/generator input. Multi power sources work as complementary to achieve system working 24 hours per day IP65 design, continuous full-load operation between -10℃ to +60℃ Compatible with all AC pump types
Features:
- Soft start
- DC Input Anti-reverse
- AC Input/Output Phase lost(3Phase)
- AC Output Short Circuit
- AC Output Unbalance (3Phase)
- Pump Dry run protection By sensor/ software
- Water Over Flow of TankSolar Low power
- Over Load
- AC Output Over Current
| TECHNICAL SPECIFICATION | |
| Max Input Current (A) | 20A |
| General Specification | |
| Humidity | 95%RH |
| Hybrid Mode | Automatic .AC supplement automatic while solar is in low power mode and AC disconnect automatic while solar power recovery |
| Max MPPT Efficiency | 99% |
| Max Output voltage | Max Output voltage |
| Max Voc Voltage | 900V |
| Min Vmp Voltage | 400V |
| Operating environment temperature | -10 to 60℃, Above 60℃ need to derate load |
| Over load Power | 9900W |
| Recommend Vmp Voltage | ≥500V (Only Solar) ≥560 V (Hybrid Power) |
| Size | 550*350*285MM |
| Voltage | 3 Phase 380/400/440V |
| Waterproof | IP65 |
| Weight | 14KG |
